7 Transistor 3 Speaker Radio GR-606

Viscount (Consolidated Merchandising Corp.); New York, NY

Data
Forum
Pictures
Collections

  • Year
  • 1962 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 249667

 Technical Specifications

  • Number of Transistors
  • 7
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / C: 6 x 1,5 Volt
  • Loudspeaker
  • 3 Loudspeakers / Ø 3 inch = 7.6 cm
  • Power out
  • 0.35 W (undistorted)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 7 Transistor 3 Speaker Radio GR-606 - Viscount Consolidated
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes

  • 2 External Earphone Jack
    1 External Antenna Jack

    Ferrite antenna is actually housed inside the carry handle.

    The tone control fades the volume of the 2 front speakers, while increasing the volume of the back speaker.
    If the tone control is set about halfway, then all 3 speakers will have equal volume.

    Made in Japan.

  • Author
  • Model page created by Daniel Rosha. See "Data change" for further contributors.
