Viscount 8 Transistor 3 Band 833

Consolidated S.M. Corp.; New York, NY

Data
Forum
Pictures
Collections

  • Year
  • 1965 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 155902

 Technical Specifications

  • Number of Transistors
  • 8
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast plus 2 Short Wave bands.
  • Power type and voltage
  • Dry Batteries / AA: 4 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Viscount 8 Transistor 3 Band 833 - Consolidated S.M. Corp.; New
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 8.5 x 4.75 x 1.87 inch / 216 x 121 x 47 mm
  • Notes

  • Viscount 833 8 Transistor 3 Band;
    AM: 540 - 1600 KHz,
    MB: 1.6 - 4.5 MHz,
    SW: 6 - 18 MHz,
    Dial light, batt./tuning meter, telescopic antenna, local/DX switch, tone hi/low, earphones jack,  sold in box with accessories like leather carrying case.

    Made in Japan

  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
