Walkie-Talkie Solid State Seven Transistor WT-710

Viscount (Consolidated Merchandising Corp.); New York, NY

Data
Forum
Pictures
Collections

  • Year
  • 1972 ?
  • Category
  • Citizen Band Equipment
  • Radiomuseum.org ID
  • 160147

 Technical Specifications

  • Number of Transistors
  • 7
  • Semiconductors
  • Main principle
  • Transceiver
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Dry Batteries / 1 x 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 0.1 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Walkie-Talkie Solid State Seven Transistor WT-710 - Viscount Consolidated
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 63 x 140 x 43 mm / 2.5 x 5.5 x 1.7 inch
  • Notes

  • Viscount WT-710 features:

    • CB Walkie-Talkie.
    • Internal microphone.
    • Pre-Call Push Button.
    • 1-channel quartz controlled.
    • Transmission power is 100 mW.
    • Telescopic antenna.
    • Sold in set of two.

    Very similar to Party FRT-70A.

    Made in Japan

  • Mentioned in
  • -- Original prospect or advert (Elettronica Pratica Italy E.P. editor, number 1 April 1972)
  • Literature/Schematics (1)
  • Selezione Radio-TV Dicembre 1972
  • Author
  • Model page created by Eduard Abfalterer. See "Data change" for further contributors.
