- Country
- United States of America (USA)
- Manufacturer / Brand
- Vocaline Company of America, Inc.; (CT)
- Year
- 1960
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 136904
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Number of Transistors
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Line / Batteries (any type) / 110 - 120 AC / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: ED-27M-6 - Vocaline Company of America,
- Shape
- Tablemodel, with any shape - general.
- Notes
- Sams photofact, set 531, folder 15, date 5-61, features the Vocaline models ED-27-6, ED-27-12, ED-27M-6 and ED-27M-12 as the same schematic. The difference is the power supply.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 531 folder 15 date 5-61)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
- Other Models
-
Here you find 10 models, 6 with images and 8 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Vocaline Company of America, Inc.; (CT)
