• Country
• Italy

• Manufacturer / Brand
• La Voce del Padrone; Milano

• Year
• 1940/1941

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 216392

• Number of Tubes
• 5

• Valves / Tubes
• 6A8G 6K7G 6Q7G 6V6G 5Y3G

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 110-275 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 579B - La Voce del Padrone; Milano

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 450 x 350 x 270 mm / 17.7 x 13.8 x 10.6 inch

• Notes
• Serie Sintorapida

• Author
• Model page created by Angelo Viscardi. See "Data change" for further contributors.

• Other Models

• Here you find 229 models, 185 with images and 141 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from La Voce del Padrone; Milano
