• Country
• Soviet Union

• Manufacturer / Brand
• Voronezh Elektrosignal Radio Works

• Year
• 1959

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 76197

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 6И1П 6И1П 6П14П 6Ц4П

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 127/220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 1 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Strela Radiola {Стрела Радиола} - Voronezh Elektrosignal Radio

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 415 x 300 x 270 inch / 10541 x 7620 x 6858 mm

• Net weight (2.2 lb = 1 kg)
• 9 kg / 19 lb 13.2 oz (19.824 lb)

• Mentioned in
• E.A.Levitin, Spravocnik po radiovesciatelnim prijomnikam, Moscow 1960

• Author
• Model page created by Zenonas Langaitis. See "Data change" for further contributors.

• Other Models

• Here you find 30 models, 28 with images and 22 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
