• Country
• Germany

• Manufacturer / Brand
• Votex automotive; Volkswagen Zubehör; Dreieich

• Year
• 1974

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 217067

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Angelika 000 051 120 - CR-662ENV - Votex automotive; Volkswagen

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 45 x 150 mm / 7.1 x 1.8 x 5.9 inch

• Notes
• Votex Angelika Teile Nr. 000 051 120 Ref.Nr.CR-662ENV;
  3 x UKW & 2 x MW Festsendertasten. Integrierte Schaltkreise vorhanden. Made in Japan.

• Net weight (2.2 lb = 1 kg)
• 1.1 kg / 2 lb 6.8 oz (2.423 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Hartmut Korb. See "Data change" for further contributors.
