- Country
- Italy
- Manufacturer / Brand
- Voxson, FARET (F.A.R.E.T.); Roma
- Year
- 1958 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 333804
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 18
- Valves / Tubes
- 6BQ7A 6U8 EF80 EF80 EF80 6AU8 9U8 PABC80 PL82 6C4 6CZ5 6AL5 6SN7GTA 6DQ6A 6AU4GTA DY80 5U4GB 21CEP4
- Number of Transistors
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 160; 220; 280 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: T225C - Voxson, FARET F.A.R.E.T.; Roma
- Shape
- Console, Highboy (legs > 50 %).
- Notes
-
Televisore con schermo da 21 pollici in bianco/nero. Deflessione 110°.
Predisposto per il secondo programma UHF.
- Mentioned in
- -- Original prospect or advert (Rivista di Mondadori "Epoca" aprile 1958)
- Literature/Schematics (1)
- -- Schematic (Schemario TV 1958 sesta serie editrice "Il Rostro")
- Author
- Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
