Televisore portatile 1722
Voxson, FARET (F.A.R.E.T.); Roma
- Country
- Italy
- Manufacturer / Brand
- Voxson, FARET (F.A.R.E.T.); Roma
- Year
- 1973 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 164993
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 38900/33400 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Televisore portatile 1722 - Voxson, FARET F.A.R.E.T.; Roma
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 510 x 370 x 340 mm / 20.1 x 14.6 x 13.4 inch
- Notes
- Cinescopio autoprotetto da 17" con deflessione a 110° munito di speziale schermo nero
Gruppo sintonizzatori VHF/UHF a sintonia elettronica (Varicap) con tastiera a 7 tasti
Antenne orientabili incorporate per VHF e UHF
- Net weight (2.2 lb = 1 kg)
- 16 kg / 35 lb 3.9 oz (35.242 lb)
- Literature/Schematics (1)
- Schematic
- Author
- Model page created by Eduard Abfalterer. See "Data change" for further contributors.
