- Country
- Netherlands
- Manufacturer / Brand
- Waldorp, N.V. Ned. Instrumentenfabriek, Den Haag
- Year
- 1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 84190
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz
- Wave bands
- Broadcast, Long Wave and more than two Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 130; 220 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: 178 - Waldorp, N.V. Ned.
- Shape
- Tablemodel, low profile (big size).
- Price in first year of sale
- 178.00 FL
- Mentioned in
- Technisch- Commercieel - Radio Vademecum Staleman
- Author
- Model page created by Folkert Rothe. See "Data change" for further contributors.
- Other Models
-
Here you find 140 models, 92 with images and 42 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Waldorp, N.V. Ned. Instrumentenfabriek, Den Haag
