• Country
• United States of America (USA)

• Manufacturer / Brand
• Wavetek Corporation; San Diego (CA)

• Year
• 1980 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 135291

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• none

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 90-128; 198-256 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Various materials

• from Radiomuseum.org
• Model: Function Generator 182A - Wavetek Corporation; San Diego

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 286 x 89 x 267 mm / 11.3 x 3.5 x 10.5 inch

• Notes
• Sine, triangle and square waveforms plus dc voltage
  0.004 Hz - 4 MHz in 7 overlapping decade ranges.

• Net weight (2.2 lb = 1 kg)
• 2.7 kg / 5 lb 15.2 oz (5.947 lb)

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Pius Steiner. See "Data change" for further contributors.
