Sweep Generator 134
Wavetek Corporation; San Diego (CA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Wavetek Corporation; San Diego (CA)
- Year
- 1971 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 150504
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- none
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 105-125; 200-250 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Various materials
- from Radiomuseum.org
- Model: Sweep Generator 134 - Wavetek Corporation; San Diego
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 8.5 x 5.25 x 11.5 inch / 216 x 133 x 292 mm
- Notes
- Waveforms: sine, square, triangle and sawtooth.
0.2Hz to 2MHz in six ranges.
- Price in first year of sale
- 21,290.00 ATS
- Source of data
- - - Manufacturers Literature
- Mentioned in
- -- Original prospect or advert (Radio Elektronik Schau, Heft 12, 1971)
- Author
- Model page created by Pius Steiner. See "Data change" for further contributors.
