Wide Range Audio Bridge B224

Wayne Kerr; New Malden, England

Data
Forum
Pictures
Collections

  • Year
  • 1975 ?
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 344821

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / 230 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Wide Range Audio Bridge B224 - Wayne Kerr; New Malden,
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Notes

  • The Wayne Kerr B224 is a manually operated bridge, the resistive and reactive terms being independently set to a null indicated on the meter.

    The bridge has ten-decade ranges and can be used to measure any component or complex impedance. Transformer ratio arms are used to cover a very wide range of measurements using a minimum number of standards set digitally. The three-terminal facility provided by this type of bridge enables small values of capacitance or high values of resistance to be measured at the end of long lengths of cable. Components can also be effectively isolated electrically from a complex network allowing individual measurements to be made without disconnection from the circuit being necessary.

    A rechargeable battery is fitted in order to make the instrument portable.

    See the Autobalance Universal Bridge Model B642.
