Record Changer Chassis 100-1

• Country
• United States of America (USA)

• Manufacturer / Brand
• Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)

• Year
• 1952 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 65277

• • Brand: Webcor

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 105-120 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Record Changer Chassis 100-1 - Webster Co., The, Webster-

• Shape
• Chassis only or for «building in»

• Notes
• There are two versions of the basic model 100 chassis:

  Model 100-1: basis chassis with crystal pickup
  Model 100-27: with special pickup arm, for GE "Variable Reluctance" cartridges.
