• Country
• United States of America (USA)

• Manufacturer / Brand
• Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)

• Year
• 1953 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 208724

• • Brand: Webcor

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6SN7 6SL7 6SC7 6K6 6E5 6X5

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 2030 - Webster Co., The, Webster-

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 520 x 400 x 270 mm / 20.5 x 15.7 x 10.6 inch

• Notes
• 2 tracks; speed = 9.5 and 19 cm/s; 2 motors; 3 speakers.

• Net weight (2.2 lb = 1 kg)
• 21 kg / 46 lb 4.1 oz (46.256 lb)

• Author
• Model page created by Christian Berthier. See "Data change" for further contributors.
