Record Changer Three Sixty Two 362, 362-1 Ch= 346-1
Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)
- Year
- 1950
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 65308
-
- Brand: Webcor
Courtesy of Eric Murray.
Courtesy of Eric Murray.
Courtesy of Eric Murray.
Courtesy of Eric Murray.
Sams Photofact Folders
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 105-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.6 inch = 11.7 cm
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Record Changer Three Sixty Two 362, 362-1 Ch= 346-1 - Webster Co., The, Webster-
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Notes
- The Webster Model 362 is an AC operated 3 Tube Audio Amplifier combined with a three speed Disc Record Player; 45 W Power Consumption.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 21, Copyright 1950
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 105, Folder 12, Dated 9-50)
