Record Changer Chassis 56

• Country
• United States of America (USA)

• Manufacturer / Brand
• Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)

• Year
• 1945/1946

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 65316

• • Brand: Webcor

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Record Changer Chassis 56 - Webster Co., The, Webster-

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 14 x 8 x 14 inch / 356 x 203 x 356 mm

• Net weight (2.2 lb = 1 kg)
• 13.4 lb (13 lb 6.4 oz) / 6.084 kg

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 15 = 1947 and before

• Mentioned in
• Radio Retailing (Radio & Television R.) (October 1945 page 53. March 1946 page 129.)

• Literature/Schematics (1)
• Marconi Service Manual Volume No. 2 (Volume 2, Page 379)

• Other Models

• Here you find 440 models, 208 with images and 363 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
