Record Changer Chassis 77
Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)
- Year
- 1950 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 137085
-
- Brand: Webcor
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110 - 115 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Record Changer Chassis 77 - Webster Co., The, Webster-
- Shape
- Chassis only or for «building in»
- Notes
- AC operated record changer.
- Circuit diagram reference
- Rider's Perpetual, Volume 22, covering 1951
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 137 folder 14 date 7-51)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
