Webcor BC-1967-1 Ch= 14X282-1 or 14X283-1
Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)
- Year
- 1959
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 154358
-
- Brand: Webcor
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 110 - 120 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Webcor BC-1967-1 Ch= 14X282-1 or 14X283-1 - Webster Co., The, Webster-
- Shape
- Tablemodel, with any shape - general.
- Notes
- The Webster Model Webcor BC-1967-1 is an AC operated 5 Tube Phono Amplifier with 4 Speed Automatic Record Changer.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 11-59, Set 463, Folder 15)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
