• Country
• United States of America (USA)

• Manufacturer / Brand
• Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)

• Year
• 1954

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 137084

• • Brand: Webcor

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AV6 50C5 35W4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 110 - 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: D-300-1 - Webster Co., The, Webster-

• Shape
• Tablemodel with Clock ((Alarm-) Clock Radio).

• Notes
• The Webster Model Webcor D-300-1 is an AC operated AM receiver with alarm clock.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 255 folder 16 date 10-54)

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.
