Wire Recorder 79
Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Webster Co., The, Webster-Chicago, Webcor; Chicago (IL)
- Year
- 1947
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 169416
-
- Brand: Webcor
SAMS Photofact
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Wave bands
- - without
- Details
- Wire Recorder (or -Player)
- Power type and voltage
- Alternating Current supply (AC) / 105-120 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Various materials
- from Radiomuseum.org
- Model: Wire Recorder 79 - Webster Co., The, Webster-
- Shape
- Tablemodel, slant panel.
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- Circuit diagram reference
- Rider's Perpetual, Volume 17 = 1948 and before
- Mentioned in
- Radio Retailing (Radio & Television R.) (July 1947 page 41.)
- Literature/Schematics (4)
- Photofact Folder, Howard W. SAMS (Set 37, Date 3/48, Folder 487-26)
- Author
- Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
