• Country
• Germany

• Manufacturer / Brand
• Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach

• Year
• 1970 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 310286

• • alternative name: Württemb. Radio-Ges.mbH; Stuttgart

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 70 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 3116 HiFi - Wega, Württembergische Radio-

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 620 x 140 x 195 mm / 24.4 x 5.5 x 7.7 inch

• Notes

• HiFi-Steuergerät mit 2 x 35 W

• Author
• Model page created by Gerhard Wickern. See "Data change" for further contributors.
