• Country
• Germany

• Manufacturer / Brand
• Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach

• Year
• 1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 159709

• • alternative name: Württemb. Radio-Ges.mbH; Stuttgart

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• EF85 EC92 ECH42 EF41 EABC80 EL41

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: Fox 53 467 W-5 - Wega, Württembergische Radio-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 420 x 280 x 220 mm / 16.5 x 11 x 8.7 inch

• Notes
• Trockengleichrichter B250C90. UKW bis 100 MHz.

• Author
• Model page created by Ottmar Lauth. See "Data change" for further contributors.
