• Country
• Germany

• Manufacturer / Brand
• Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach

• Year
• 1966/1967

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 75697

• • alternative name: Württemb. Radio-Ges.mbH; Stuttgart

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• A65-11W

• Number of Transistors
• 5

• Semiconductors
• AF139 AF139 AF121 AF121 AF121

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Wegavision 747 - Wega, Württembergische Radio-

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 700 x 540 x 330 mm / 27.6 x 21.3 x 13 inch

• Notes
• VHF-Tuner röhrenbestückt, UHF-Drucktasten-Tuner transistorbestückt; Fernbedienung 793 für Lautstärke, Helligkeit, Kontrast, Ein/Aus.

• Source of data
• Handbuch VDRG 1966/1967

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Alexander Schmitz. See "Data change" for further contributors.
