• Country
• Germany

• Manufacturer / Brand
• Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach

• Year
• 1970

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 128309

• • alternative name: Württemb. Radio-Ges.mbH; Stuttgart

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• PL95 PL805 PL504 A61-120W

• Number of Transistors
• 16

• Semiconductors
• AF106 AF239 AF139 BF167 BF198 BF173 BF199 BF178 BC171 BC170 BC251 BC147 BF178 BC110 BF198 BC170 BY147 TV18

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 21 cm = 8.3 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Wegavision 772 L [nußbaumfarben] - Wega, Württembergische Radio-

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 670 x 475 x 390 mm / 26.4 x 18.7 x 15.4 inch

• Notes
• 61cm s/w TV, CCIR B/G VHF-/UHF Tuner mit 6 Programmtasten, 11 Dioden, optionale Kabelfernbedienung Typ 793 54 DM, passendes Drehgestell Typ 700 69 DM, nußbaumfarben.

• Net weight (2.2 lb = 1 kg)
• 25.5 kg / 56 lb 2.7 oz (56.167 lb)

• Price in first year of sale
• 618.00 DM

• Source of data
• -- Original prospect or advert

• Mentioned in
• Handbuch VDRG 1970/1971 (S. B54)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from A. See "Data change" for further contributors.
