• Country
• United States of America (USA)

• Manufacturer / Brand
• Weller Tools (Cooper Tools); Easton, PA

• Year
• 1990 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 333911

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 24 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Various materials

• from Radiomuseum.org
• Model: Entlötkolben - Desoldering Iron - Dissoudeur DS-22 - Weller Tools Cooper Tools;

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 34 x 76 x 205 mm / 1.3 x 3 x 8.1 inch

• Notes

• Elektronisch geregelter Entlötkolben DS-22, 24 V / 50 W mit ESD-Schutz.

  Mit zentralem kabelgebundenem Vakuumanschluss. Zum Betrieb mit z.B. der Weller Vakuumpumpe VP801EC, die Entlöttemeratur kann stufenlos eingestellt werden.

  Pumpenauslösung durch seitliche Taste am Handgriff.

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
