Rechteckwellengenerator RWG 4
Werk für Fernmeldewesen (OSW, HF, WF) Berlin, VEB, RFT (Ostd.)
- Country
- Germany
- Manufacturer / Brand
- Werk für Fernmeldewesen (OSW, HF, WF) Berlin, VEB, RFT (Ostd.)
- Year
- 1959 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 126210
-
- alternative name: VEB Werk für Fernsehelektronik
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Rechteckwellengenerator RWG 4 - Werk für Fernmeldewesen OSW,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 300 x 210 x 160 mm / 11.8 x 8.3 x 6.3 inch
- Notes
-
Rechteckwellengenerator 50Hz-500kHz.
Siehe auch RWG 4 von Messelektronik Berlin mit leichten optischen Änderungen und abweichender Beschriftung.
- Net weight (2.2 lb = 1 kg)
- 6 kg / 13 lb 3.5 oz (13.216 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Helmut Matysik. See "Data change" for further contributors.
