W-67/D/22EC

Werner; Madrid

Data
Forum
Pictures
Collections

  • Year
  • 1976
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 326140

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Valves / Tubes
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superhet with RF-stage; ZF/IF 38900 kHz
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: W-67/D/22EC - Werner; Madrid
  • Shape
  • Tablemodel, low profile (big size).
  • Notes

  • Wener, S.A.E. modelo W-67/D/22EC

    • TV 22" Pal Color
    • Sintonizador electrónico de VHF/UHF a varicap Copresa ELC2000S
    • Seis presintonías por sensores

    Véase mismo modelo en 26" W-57/D/26DC

  • Mentioned in
  • - - Manufacturers Literature (Adelanto de Información Técnica, diciembre 1975)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
