W-76 /B 23"-B

Werner; Madrid

  • Year
  • 1967 ??
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 348311

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 16
  • Number of Transistors
  • 2
  • Main principle
  • Superhet with RF-stage; ZF/IF 38900 kHz; 2 AF stage(s)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 125; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • from Radiomuseum.org
  • Model: W-76 /B [23"-B] - Werner; Madrid
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • Wener, S.A.E. modelo W-76 /B 23"-B

    TV B/N 23" con selector rotativo de VHF y sintonizador transistorizado de UHF

  • Literature/Schematics (1)
  • -- Schematic (Esquemario TV REDE, Tomo V, 1969)
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
