• Country
• Great Britain (UK)

• Manufacturer / Brand
• Western Electric Co. Ltd.; London

• Year
• 1932 ?

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 357078

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 262A 262A 275A 275A 274A

• Main principle
• Audio-Amplification; 3 AF stage(s)

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Ampl. Loudspeaker 30320G Ch=30321G/ D95036A - Western Electric Co. Ltd.;

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Notes

• The Western Electric 30320G was a portable, AC-powered amplifier-speaker system from the early 1930s.

  It had five pluggable gain settings and incorporated 275A valves in a push-pull output

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
