- Country
- United States of America (USA)
- Manufacturer / Brand
- Western Auto Supply Co. (Truetone); Kansas City (MO)
- Year
- 1955 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 329551
Picture from service manual.
Picture from service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 16
- Valves / Tubes
- 6T4 6BZ7 6U8 6CB6 6CB6 6CB6 6AN8 6AN8 6BN6 25BK5 12BH7 12AU7 25BQ6GT 25AX4GT 1X2B 21YP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 115V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 2D2427A - Western Auto Supply Co.
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Truetone model 2D2427A is a 21” b/w TV with US standard VHF tuner channels 2 thru
13, and 14 thru 83 UHF. Equipped with a VHF- tuner , a UHF-tuner and picture tube 21YP4A.
