Wetekom World Band Receiver PLL-500

Westfalia, Profisound; Hagen

Data
Forum
Pictures
Collections

  • Year
  • 1995
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 255070

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Power type and voltage
  • Batteries / addl. power jack / AA: 4 × 1,5 / 6 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.5 cm = 3 inch
  • Power out
  • 1 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Wetekom World Band Receiver PLL-500 - Westfalia, Profisound; Hagen
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 213 x 127 x 41 mm / 8.4 x 5 x 1.6 inch
  • Notes

    • Computer Controlled

    • 36 programmierbare Speicher
    • direkt Tuning vorwärts / rückwärts
    • automatische Suche vorwärts
    • Aufteilung Kurzwelle
      • SW1= 75- 60- 49- 41- Meter Band
      • SW2= 31- 25- 19- 16- 13- Meter Band
    • Genannte Transistoren teils mehrfach vorhanden
      • S9014: 23 Stück
      • S9016: 5 Stück
      • S8550C: 3 Stück
      • 2SK241GR: 3 Stück
    • Genannte Dioden teils mehrfach vorhanden
      • 1N4148: 29 Stück
      • KV1310NT (Single): 2 Stück
      • KV0714-2 (Pair): 6 Stück
    • Eingebauter Lautsprecher: 8 Ohm, 2 Watt

    • Gerät baugleich mit
  • Net weight (2.2 lb = 1 kg)
  • 0.720 kg / 1 lb 9.4 oz (1.586 lb)
