H-14TU171A Ch= V-2321-401

Westinghouse El. & Mfg. Co. - see also Canadian W.

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Westinghouse El. & Mfg. Co. - see also Canadian W.

Year
1957 ?

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
270509

- alternative name: Westinghouse El. Int.

Schematics

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850298) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850299) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850301) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850302) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850303) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850304) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850305) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850306) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850309) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850310) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850311) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850312) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850314) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850315) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850316) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850318) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

H-14TU171A Ch= V-2321-401; Westinghouse El. & (ID = 1850319) Television — Westinghouse El. & H-14TU171A Ch= V-2321-401 (3)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
17

Valves / Tubes
3BC5 5AT8 2AF4A 3BZ6 3BZ6 6CB6 6BH8 3BN6 12C5 3CS6 6CN7 12W6GT 7AU7 12DQ6 12D4 1X2B 14NP4A or 14SP4

Main principle
Superhet with RF-stage

Wave bands
VHF incl. FM and/or UHF (see notes for details)

Power type and voltage
Alternating Current supply (AC) / 117 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

Material
Bakelite case

from Radiomuseum.org
Model: H-14TU171A Ch= V-2321-401 - Westinghouse El. & Mfg. Co. -

Shape
Tablemodel, with any shape - general.

Notes
The Westinghouse H-14TU171A is a 14" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis V-2321-401 and picture tube 14NP4A or 14SP4.

Mentioned in
Photofact Folder, Howard W. SAMS (Set 355, Folder 15 Date 4-57)

Author
Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
