H-760TU21 Ch= V-2233-2
Westinghouse El. & Mfg. Co. - see also Canadian W.
- Country
- United States of America (USA)
- Manufacturer / Brand
- Westinghouse El. & Mfg. Co. - see also Canadian W.
- Year
- 1953
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 218095
-
- alternative name: Westinghouse El. Int.
Picture from Westinghouse datasheet
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 23
- Valves / Tubes
- 6BQ7 or 6BZ7 6J6 6X8 6CB6 6CB6 6CB6 12BY7 6AU6 6BN6 6BK5 6AU6 12BH7 12AT7 6AU6 6SN7GT 6AL5 12AU7 6BQ6GT 6AS4GT or 6AX4GT 1B3GT 5U4G 5U4G 21FP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 105-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 inch = 13.3 cm
- Power out
- 1.8 W (unknown quality)
- from Radiomuseum.org
- Model: H-760TU21 Ch= V-2233-2 - Westinghouse El. & Mfg. Co. -
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
- The Westinghouse H-760TU21 is a 21" b/w TV with US standard VHF tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis V-2233-2, UHF tuner H-803 and picture tube 21FP4A. For service information, refer to Westinghouse model H-740T21 service notes and supplementary information. Most information for chassis V-2233-1 applies to chassis V-2233-2.
- Literature/Schematics (1)
- - - Manufacturers Literature (Westinghouse Datasheets RM3355 RM3341 RM3357 RM3399 V-11435)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
