H-99AC2 Ch= V-2526-1

Westinghouse El. & Mfg. Co. - see also Canadian W.

Data
Forum
Pictures
Collections

  • Year
  • 1963
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 93486
    • alternative name: Westinghouse El. Int.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 5
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Line / Batteries (any type) / 108-130 / 6 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: H-99AC2 Ch= V-2526-1 - Westinghouse El. & Mfg. Co. -
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Notes
  • The Westinghouse Model H-99AC2 is a portable AC/Battery Operated 5 transistor Mono Amplifier with 4 Speed Automatic Record Changer. Uses Qty(6) 1.5V "D" batteries. Has Qty(1) PM 4" speaker. Cabinet color is Olive Green. Uses Record Changer 670V030H01, with speeds of 16, 33, 45 and 78 RPM. Westinghouse model H-99AC1 uses the same chassis and schematic, the difference being cabinet color.
  • Circuit diagram reference
  • Beitman Radio Diagrams Vol. 25, 1965
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Westinghouse Datasheet PH6049)
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
