Escort - 8 Transistor RS21P08A
Westinghouse El. & Mfg. Co. - see also Canadian W.
- Country
- United States of America (USA)
- Manufacturer / Brand
- Westinghouse El. & Mfg. Co. - see also Canadian W.
- Year
- 1962
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 108471
-
- alternative name: Westinghouse El. Int.
- Number of Transistors
- 8
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast only (MW).
- Details
- Radio with other functions
- Power type and voltage
- Line / Batteries (any type) / 120 / AA: 2 x 1.2 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Escort - 8 Transistor RS21P08A - Westinghouse El. & Mfg. Co. -
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 110 x 82 x 32 mm / 4.3 x 3.2 x 1.3 inch
- Notes
-
Radio, watch, flashlight, electric cigarette lighter, and built in charger (connection and switchover on back).
See also Escort RS16P08A.
Made in Taiwan.
- Net weight (2.2 lb = 1 kg)
- 0.4 kg / 0 lb 14.1 oz (0.881 lb)
- Price in first year of sale
- 30.00 $
- Source of data
- -- Original prospect or advert
- Mentioned in
- Collector's Guide To TrR1 Bunis trans.94 (1996, page 307)
- Literature/Schematics (1)
- Norman Smith: Transistor Radios 1954-1968.
- Literature/Schematics (2)
- Photofact TSM Transistor Radio Series SAMS (TSM-94, November 1968)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
