Selective Analyzer 665 Type 2
Weston Electrical Instrument Co.; Newark, N.J.; (Jewell Electrical Instrument Co.; Chicago, IL)
- Land
- USA
- Hersteller / Marke
- Weston Electrical Instrument Co.; Newark, N.J.; (Jewell Electrical Instrument Co.; Chicago, IL)
- Jahr
- 1934 ?
- Kategorie
- Service- oder Labor-Ausrüstung
- Radiomuseum.org ID
- 285142
-
- anderer Name: Jewell
Klicken Sie auf den Schaltplanausschnitt, um diesen kostenlos als Dokument anzufordern.
- Wellenbereiche
- - ohne
- Betriebsart / Volt
- Trockenbatterien
- Lautsprecher
- - - Kein Ausgang für Schallwiedergabe.
- Material
- Plastik oder Bakelit
- von Radiomuseum.org
- Modell: Selective Analyzer 665 [Type 2] - Weston Electrical Instrument
- Form
- Diverse Formen, unter Bemerkung beschrieben.
- Bemerkung
-
Portable meter for measuring voltage, current and resistance data on various radio sets, and operates in conjunction with the Model 666, type 1B and 666, type 2 selector units. A carrying case is available for the meter along with the various accessories.
Full scale voltage measurements (AC or DC) extend from 1 volt to 1000 volts in ten ranges by using the sockets on the left-hand side of the meter. DC current measurements use the right-hand sockets and extend from 1 ma to 1000 ma in 10 ranges. The resistance measurements have four ranges and operate in conjunction with internal batteries.
This meter is one component of military Test Set I-56-A manufactured by Weston Electrical Instrument Corporaton.
