- Country
- United States of America (USA)
- Manufacturer / Brand
- Wilcox-Gay Corp.; Charlotte (MI)
- Year
- 1936 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 66703
-
- Brand: Recordio
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 175 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- AC/DC-set / Either 60 cycles, 110 to 120V or DC 110 to 120 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6.5 inch = 16.5 cm
- from Radiomuseum.org
- Model: 3JM6 - Wilcox-Gay Corp.; Charlotte MI
- Notes
-
The Wilcox-Gay 3JM6 is an AC/DC operated 5 tube BC, Police and SW band receiver. Uses ballast tube L49B. Has 6.3V lamp and phono input.
Gernsback calls out the same schematic for Wilcox-Gay models A15, A17, 3JM6 and 3JQ6. Riders has schematic for only models 3JM6 and 3JQ6 (Riders 7-2) but the alignment instructions (Riders 7-3) call out all 4 models.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 7 = 1936 and before
- Literature/Schematics (1)
- Rider's Perpetual, Volume 7 = 1936 and before (Riders 7-2, 3)
- Literature/Schematics (2)
- Gernsback Official Radio Service Manual (Volume 7, page 1021)
