• Country
• Italy

• Manufacturer / Brand
• Wilson; Milano

• Year
• 1980 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 295325

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors
• BC208 BC208 AC180 AC181 BC208 BC208 AC180 AC181 PTO/3 PTO/3

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Rec.Player+Audio.Amp+LS

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 13 cm = 5.1 inch

• Power out
• 6 W (max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mini Trio - Wilson; Milano

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 380 x 115 x 275 mm / 15 x 4.5 x 10.8 inch

• Notes

• Giradischi 4 velocità (16/33/45/78 giri) - controllo volume e tono separato L/R - pick-up Lesa girevole - potenza uscita: 3+3 watt max. - impedenza: 4 Ω - presa posteriore phono/aux.

  Made in Italy.

• Net weight (2.2 lb = 1 kg)
• 1.8 kg / 3 lb 15.4 oz (3.965 lb)

• Author
• Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
