Champion Standard Superhetrodyne
Wireless Weekly Magazine, Sydney
- Country
- Australia
- Manufacturer / Brand
- Wireless Weekly Magazine, Sydney
- Year
- 1934
- Category
- Kit (Parts plus instruction) or building instructions only
- Radiomuseum.org ID
- 331932
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case, TUBES VISIBLE
- from Radiomuseum.org
- Model: Champion Standard Superhetrodyne - Wireless Weekly Magazine,
- Shape
- Chassis only or for «building in»
- Notes
-
Following on the success of the 1933 Standard Superhet A.G. Hull designed the Champion Standard Superhet, an 8 valve superhet with RF stage, an additional audio driver and Push-Pull Triodes in the output stage.
The kit was sold using Lekmek or RCS coil kits by Levenson’s, Fox & Mac Gillycuddy and others at various prices around £14/10/- or £16 for a assembled and tested chassis.
- Mentioned in
- Wireless Weekly (Australia) (July 13, 1934 Page 26)
- Author
- Model page created by Gary Cowans. See "Data change" for further contributors.
