Rendsburg II WS4449a
Wobbe-Radio; Winsen, später Rendsburg bei Kiel
- Country
- Germany
- Manufacturer / Brand
- Wobbe-Radio; Winsen, später Rendsburg bei Kiel
- Year
- 1949/1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 17671
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 468 kHz; Super, reaction, but not adjustable
- Tuned circuits
- 4 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- AC/DC-set / 110; 125; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Rendsburg II WS4449a - Wobbe-Radio; Winsen, später
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 387 x 252 x 198 mm / 15.2 x 9.9 x 7.8 inch
- Notes
- ZF-Audion
- Net weight (2.2 lb = 1 kg)
- 5.5 kg / 12 lb 1.8 oz (12.115 lb)
- Price in first year of sale
- 250.00 DM
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Circuit diagram reference
- Lange-Nowisch
- Mentioned in
- Funkschau (4914)
- Picture reference
- Das Gerät ist im Doppelband "Historische Radios" von Günther Abele abgebildet.
