Mexico
Wundercart; Saronno, VA
- Country
- Italy
- Manufacturer / Brand
- Wundercart; Saronno, VA
- Year
- 1960 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 310441
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 2 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Mexico - Wundercart; Saronno, VA
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 490 x 240 x 175 mm / 19.3 x 9.4 x 6.9 inch
- Notes
-
controllo volume - commutatore bass on/off - AFC on/off - AM/SW/FM/FONO . TV1/TV2/FM - presa per antenna FM esterna - antenna a filo esterna per AM - presa fono.
- Net weight (2.2 lb = 1 kg)
- 4.750 kg / 10 lb 7.4 oz (10.463 lb)
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
