- Country
- Italy
- Manufacturer / Brand
- Wundercart; Saronno, VA
- Year
- 1965 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 216251
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
- Power out
- 4 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Ohio - Wundercart; Saronno, VA
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 560 x 160 x 230 mm / 22 x 6.3 x 9.1 inch
- Notes
- Front labeled in English. Rear cover labeled in German.
- Net weight (2.2 lb = 1 kg)
- 4 kg / 8 lb 13 oz (8.811 lb)
- Author
- Model page created by Spartaco Gori. See "Data change" for further contributors.
- Other Models
-
Here you find 29 models, 23 with images and 13 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
