Dual Band FM Transceiver FT-5100
Yaesu-Musen Co. Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Yaesu-Musen Co. Ltd.; Tokyo
- Year
- 1993 ?
- Category
- Amateur TRX: Transmitter/Receiver (and Transceiver)
- Radiomuseum.org ID
- 345709
Yaesu sales brochure.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Transceiver
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: Dual Band FM Transceiver FT-5100 - Yaesu-Musen Co. Ltd.; Tokyo
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 140 x 40 x 155 mm / 5.5 x 1.6 x 6.1 inch
- Net weight (2.2 lb = 1 kg)
- 1 kg / 2 lb 3.2 oz (2.203 lb)
- Author
- Model page created by David Erali. See "Data change" for further contributors.
