FT-212RH

• Country
• Japan

• Manufacturer / Brand
• Yaesu-Musen Co. Ltd.; Tokyo

• Year
• 1988

• Category
• Amateur TRX: Transmitter/Receiver (and Transceiver)

• Radiomuseum.org ID
• 151884

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superhet, double/triple conversion; ZF/IF 10700/455 kHz

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 13,8 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 1.6 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: FT-212RH - Yaesu-Musen Co. Ltd.; Tokyo

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 140 x 40 x 160 mm / 5.5 x 1.6 x 6.3 inch

• Notes

• Yaesu Mobil-VHF-FM-Transceiver FT-212RH.
  Frequenzbereich: 144-146 MHz (erweitert 140-174 MHz); 20 Speicher; 1750-Hz-Tonruf; P_out: 45 W/5 W.

  CTCSS Encoder/Decoder

• Net weight (2.2 lb = 1 kg)
• 1.3 kg / 2 lb 13.8 oz (2.863 lb)

• Mentioned in
• RICOFUNK-Katalog 1988

• Literature/Schematics (1)
• Beam Amateurfunk-Geräteführer '90

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.

• Other Models

• Here you find 305 models, 289 with images and 139 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Yaesu-Musen Co. Ltd.; Tokyo
