• Country
• Japan

• Manufacturer / Brand
• Yaesu-Musen Co. Ltd.; Tokyo

• Year
• 1975 ??

• Category
• Amateur Equipment (Other, but not Key)

• Radiomuseum.org ID
• 182153

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 5

• Semiconductors
• 3SK22 3SK22 2SC372 or. 2SC828 2SC735 MK10

• Main principle
• RF Converter/Adapter (not voltage converter)

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Powered by external power supply or a main unit. / 6.3 & 12 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: VFO FV-101B - Yaesu-Musen Co. Ltd.; Tokyo

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 14 x 11 x 19 inch / 356 x 279 x 483 mm

• Notes

• Yaesu Musen FV-101B

  Remote VFO for the FT-101B and other Transceivers, frequency range 8.7 to 9.2 MHz. Four xtal channel presets.

• Net weight (2.2 lb = 1 kg)
• 7.5 lb (7 lb 8 oz) / 3.405 kg

• Source of data
• - - Manufacturers Literature

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from A. See "Data change" for further contributors.
