• Country
• Japan

• Manufacturer / Brand
• Yamaha Co.; Hamamatsu

• Year
• 1995–1999 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 200735

• • alternative name: Nippon Gakki

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-120; 220-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 40 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Receiver RX-S50 - Yamaha Co.; Hamamatsu

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 280 x 107.5 x 339.5 mm / 11 x 4.2 x 13.4 inch

• Notes
• Receiver RX-S50 + CD Player CDX-S50 + Cassette Tape Deck KXW-S70 + Speakers NX-S50 = CC-50 Natural Sound Mini Component System
  In Europa auch LW

• Net weight (2.2 lb = 1 kg)
• 5.3 kg / 11 lb 10.8 oz (11.674 lb)

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Carlos A. Pieroni-García. See "Data change" for further contributors.
