Stereo Receiver RX-S70
Yamaha Co.; Hamamatsu
- Country
- Japan
- Manufacturer / Brand
- Yamaha Co.; Hamamatsu
- Year
- 1993
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 207408
-
- alternative name: Nippon Gakki
Frontansicht Receiver
Receiver von Links geöffnet
Service Manual
Sales Brochure
Sales Brochure
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- PLL, Phase-locked loop
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 130 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Receiver RX-S70 - Yamaha Co.; Hamamatsu
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 280 x 107.5 x 339.5 mm / 11 x 4.2 x 13.4 inch
- Notes
- HiFi Stereo Receiver. Sinus 2x 65W an 4 Ohm nach DIN, LW/MW/UKW Empfänger, Steuergerät für das Compact System CC-70S/W.
- Net weight (2.2 lb = 1 kg)
- 6 kg / 13 lb 3.5 oz (13.216 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by a member from D. See "Data change" for further contributors.
