General 4P-112A

Yaou Radio Co ltd ; Kanagawa-ken

Data
Forum
Pictures
Collections

  • Year
  • 1955 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 353947
    • alternative name: Yaou Electric Co., Ltd.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common); 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / C: 1 x 1.5; 415: 1 x 45 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.5 inch = 6.4 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: General 4P-112A - Yaou Radio Co ltd ; Kanagawa-
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 162 x 110 x 50 mm / 6.4 x 4.3 x 2 inch
  • Notes

  • Tuning Range:
    535~1605 kHz

    B battery Eveready 415 or equivalent.

  • Net weight (2.2 lb = 1 kg)
  • 0.9 kg / 1 lb 15.7 oz (1.982 lb)
  • Author
  • Model page created by Martin Kent. See "Data change" for further contributors.
