Captain Six-Transistor YT-161

• Country
• Japan

• Manufacturer / Brand
• Yashima Electric Industrial Co., Ltd.; Tokyo

• Year
• 1959 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 122163

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• 2SA30 2SA31 2SA31 2SB32 2SB33 2SB33

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.5 inch = 6.4 cm

• Power out
• 0.3 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Captain Six-Transistor YT-161 - Yashima Electric Industrial Co

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 105 x 60 x 35 mm / 4.1 x 2.4 x 1.4 inch

• Notes

• Kommt mit goldfarbener Metallfront und mit echter Ledertasche: GENUINE COWHIDE LEATHER HALF SIZE CARRYING CASE.

  Another Toshiba transistor line-up:
  2SA29, 2SA52, 2SA29, 2SB54, 2x 2SB56

  Made in Japan.

  Very similar to the models reported under Kaytone YT-161

• Net weight (2.2 lb = 1 kg)
• 0.2 kg / 0 lb 7 oz (0.441 lb)

• Author
• Model page created by Eckhard Wegner. See "Data change" for further contributors.
